Product info
- Product name:Doppler fetal monitor
- Product code:CCFD-800C
Packaging Specifications
- Outer Packaging Size:0.57 × 0.36 × 0.48 m
- Gross Weight:13 kg
- Net Weight:10 kg
- Volume:0.1
Description
Model：FD-800C/D
1. Usage
FD-800C/D ultrasonic fetal doppler meets
the fetus daily check and routine examination
at clinic,community and hospital
2. Features
● Easy and convenient operation
● High-fidelity, crystal clear sound
● Earphone and speaker are feasible
● High sensitivity water-proof probe
● Display with backlight LCD and colour LCD
● Unique ergonomic design
● USB functions to transmit data
● Flexible menu and parameter function
● Both audio and light alarm
● Multiple working modes
● Colour LCD with touch and automatic storage function and play back of FHR curve
3. Technical Specification
● Ultrasound frequency: 2MHz
● Ultrasound intensity: <10mW/cm2
● Power supply: Rechargeable battery
AC 220/110V, 50/60Hz
● Display: 65mm×50mm LCD
● FHR Measuring range: 50~230bpm
● FHR resolution: 1bpm
● FHR accuracy: ±2bpm
● Power consumption: <12W
● Dimension :220mm ×220mm ×140mm
● Gross weight:2.1kg
● Printing paper size: 50mm
4. Configuration
● Main body
● Ni-MH battery
● 2MHz probe
● Adaptor
5. Option
● Earphone
● PC software
● Carry case
● Trolley
● 3MHz probe
● Printing system
6. FD-800 C/D Difference Table
| Functions | FD-800D | FD-800C |
| Doppler type | Continuous | Continuous |
| Display type | B/W | Colour |
| Build-in speaker | Yes | Yes |
| Battery indicator | Yes | Yes |
| Display | Digit | Digit+ Curve |
| Various work modes | Yes | Yes |
| Battery | Ni-MH | Ni-MH |
| Charge in device | Yes | Yes |
| Touch LCD | No | Yes |
7.Certificate
● ISO Certificate
● CE Certificate
● FDA Certificate
8.Product Mode
● Neutral
● OEM
● ODM
● SKD
